Shade Sail Patterner, previously known as MPanel Shade Designer, simplifies the complex process of designing, patterning, and fabricating shade sails. Built as a stand-alone Windows application, it requires no CAD skills or fabric patterning experience – making it the most efficient way to deliver professional, accurate shade sail projects.
“MPanel saves a ton of labour, eliminates mistakes, and ensures accuracy. It won’t give you a bad panel - if the geometry isn’t right, it won’t produce a pattern.”
Dave Brewer
Dave Brewer
Lawrence Fabric
What Shade Sail Patterner is and how it works
Shade Sail Patterner provides a simple, forms-based interface that guides you through every step of the shade sail patterning process:
- Enter site dimensions and project details.
- Select materials, edge finish and corner hardware and fittings.
- Model 3, 4, 5, or 6-sided sails.
- Split meshes into multiple panels, apply seam allowances, and map panels.
- Generate patterns and nesting layouts ready for hand or machine cutting and fabrication.
All of this can be achieved with just a few keystrokes, even by staff without CAD or drafting experience.
Key features & benefits of Shade Sail Patterner
Accuracy guaranteed
Removes guesswork from the shade sail patterning process.
No CAD required
Stand-alone software designed for non-specialists.
Speed
Create accurate patterns in minutes instead of hours.
Efficiency
Enable unskilled staff to produce reliable results, freeing senior designers for complex work.
Professional outputs
Produce fabrication-ready patterns, nesting layouts, and comprehensive production documentation.
Cost savings
Reduce waste by nesting panels efficiently and eliminating rework.
Who is Our Shade Sail Patterner for?
This shade sail design software is trusted by:
- Small to mid-sized shade sail businesses looking to streamline fabrication
- Manufacturers needing repeatable, accurate shade sail patterns
- Larger companies using Professional tools but wanting an efficient solution for basic sails and removing the burden on expensive CAD resources
- Installers and contractors who want to ensure precise panel geometry before cutting
How hard is this software to learn and become proficient with?
Learn more about Support & Training ->Comparing Shade Sail Patterner to other solutions
General CAD or patterning tools are often overkill for shade sails, requiring steep learning curves and expensive licences. Other flattening software can create 2D panels, but lack tensile-specific features like form-finding, seam allowances, material compensation, or multi-panel control.
Shade Sail Patterner is different:
- Built specifically for shade sail fabrication software needs.
- Optimised for sails, not generic fabric products.
- Works seamlessly alongside other MPanel tools, providing a clear upgrade path — from sales (Shade Site Designer) to fabrication (Shade Sail Patterner) to advanced structure engineering (Fabric Structure Professional & Analysis).
Is Shade Sail Patterner the tool you really need?
Click here to find out ->Want to see Shade Sail Patterner in action?
Book a live demo or get started immediately by purchasing. We have monthly billing and no ongoing commitment; you can scale your usage as your projects demand!
Shade Sail Patterner FAQs
No. Shade Sail Patterner is a stand-alone application and requires no CAD or patterning experience.
No. Shade Sail Patterner is a stand-alone application and requires no CAD or patterning experience.
No. Shade Sail Patterner is a stand-alone application and requires no CAD or patterning experience.
